RHS steel metal pipe laser cutting machine manufacturer from China Wuhan Tianqi Laser Equipment Manufacturing Co.,Ltd.

RHS steel metal pipe laser cutting machine

Payment Terms:	TT,L/C at sight
Place of Origin:	Hubei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: By Sea

Packing: wooden case

Application: Laser Cutting

Brand Name: Tianqi Laser

Production Capacity: 5000 sets/year

Delivery Date: 15-20 working days

Laser Type: YAG

Application
YAG laser cutting machine has been widely used in
manufacture billboard, sheet metal structure, high-low
voltage electric cabinet, text

Advantages:

1. High precision: an precise cutting for various precision part, arts and crafts.

2. Fast speed: 100 times higher than linear cutting

3. Small heat affected zone, good dimension stability. Flat and nice laser-slotted, without later process

4. High performance/price ratio: the price is only 1/8 of the similar CO2 laser cutting machine and 2/5 of the equivalent CNC Punch

5. Low use cost: only $2 per hour which is 1/8-1/10 of the similar CO2 laser cutting machine ($22-35 per hour)

6. Low follow-up maintenance cost: only 1/10~1/15 of the similar CO2 laser cutting machine and 1/3~1/4the equivalent CNC Punch

7. Steady performance: as a mature laser apparatus, the YAG laser cutting machine is suitable for many metal processing industry.

Application:

YAG laser cutting machine has been widely used in manufacture billboard, sheet metal structure, high-low voltage electric cabinet, textile machinery, kitchenware, metal artware, etc.

Applicable materials:

Our YAG laser cutting machines have been widely used in different kinds of manufacturing and processing lines since it can cut many kinds of metals including Stainless steel, carbon steel, alloy steel, spring steel, copper sheet, aluminum sheet, gold, silver, titanium sheet and pipe.

Research and Development
Through continuous research and development, our own research laboratory device has been developed into laser equipment which can work continuously and stably for 24-hour a day. Tianqi laser has developed a series of high-end laser products, and owns several patents.

Service

Tianqi Laser set up a marketing management center, 16 offices across our domestic country and 3 branches worldwide, resident technical engineer provide comprehensive pre-sale, after sales support and service. We provide one year warranty and lifetime maintenance. Also we provide online and telephone service 24 hours a day, when it is necessary, we will send technician to the customer side to solve the problem.

Technical parameter for lager scale YAG laser cutting machine:

Model:	TQL-LCY620-4115	TQL-LCY620-3015	TQL-LCY620-2513
Processing scale(length*width):	4100mm*1500mm	3000mm*1500mm	2500mm*1300mm
Cutting thickness:	0.1mm-8mm	0.1mm-8mm	0.1mm-8mm
Max. output power:	620W	620W	620W
Laser wavelength:	1064nm	1064nm	1064nm
Pulse frequency:	1--300HZ	1--300HZ	1--300HZ
Min. line width:	0.15mm	0.15mm	0.15mm
Electrical source:	380V/50HZ/100A	380V/50HZ/100A	380V/50HZ/100A
X,Y,Z axis geometric positioning accuracy:	≤±0.08mm/1000mm	≤±0.08mm/1000mm	≤±0.08mm/1000mm
X,Y,Z axis re-orientation accuracy:	≤±0.04mm	≤±0.04mm	≤±0.04mm
Machine weight:	4200kg	4000kg	3780kg
Cooling mode:	7P water-cooling	7P water-cooling	7P water-cooling
Max. cutting speed:	35mm/s	35mm/s	35mm/s
